Black Diamond Bottom PVC Conveyor Belt Fabric Food Grade Treadmill Walking Belt

Short Description:

Place of Origin: China
Brand Name: Skypro
Certification: ROHS/Reach/SGS
Model Number: RM1101

Payment & Shipping Terms:

Minimum Order Quantity: 200 Piece/Pieces
Price: negotiable
Packaging Details: olls,inner foam+ outer abrasion resistant canvas with hard cardboard tube inside
Delivery Time: 15days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000 sq.m/day


Product Detail

FAQ

Product Tags

Name: PVC Conveyor Belt Pattern: Diamond,etc
Width: 3000mm Thickness: 0.5 To 7mm
Feature: Anti-static,cold-resistant,oil-resistant.etc Application: Conveyor
High Light:

PVC conveyor belting

,

plastic conveyor belt

PVC belt conveyor fabric for food grade with black diamond bottom treadmill walking beltspecifications:

Belt Dimension
Colour Natural/transp.
Total Thickness(Top/Bottom) 3.0mm
Cover Thickness(Top/Bottom) 1.0mm
Weight 3.3kg/m2
Technical Data
Tensile Strength 160N/mm
Stretching Strength,Effective Pull at 1% elongation 10N/mm
Cover Hardness(ShoreA) 75ShoreA
Min. Diameter 40mm
Temperature Range -10/+80℃
Max. Production Width 2.6m
Application
Industry All kind of light duty application

Features:lLow Noise, Flame RetardantlHigh Abrasion ResistancelPlasticizer FreelExcellent Matching Printing

Packing and transportation:

Packing way Packed in roll or flat sheet,50-100kg/roll or according to specific requests from clients
Packing material Inner PE film+ outer Woven plastic bags as standard, palletized for extra reinforcement if necessary
Shipping marks Neutral packing with printed marks.
Delivery time 15 days since receipt of PO and down payment
Freight Sea(FCL & LCL) or air freight
Special size We provide cutting services for special sizes
Lamination We provides extra lamination with PSA, textiles or other materials.

FAQ(Frequently Asked Questions)1. What is the capability of your company ?Skypro is a professional manufacturer of rubber sheet for more than two decades.Top 10 biggest rubber factory in China.2.What is production capability each year?We produce more than 18000 tons of rubber sheet products each year.3.How can I get some samples?We are pleased to offer you free samples. New clients are expected to pay for the delivery cost, this charge will be deducted from the payment for formal order.

Black Diamond Bottom PVC Conveyor Belt Fabric Food Grade Treadmill Walking Belt 0Black Diamond Bottom PVC Conveyor Belt Fabric Food Grade Treadmill Walking Belt 1Black Diamond Bottom PVC Conveyor Belt Fabric Food Grade Treadmill Walking Belt 2Black Diamond Bottom PVC Conveyor Belt Fabric Food Grade Treadmill Walking Belt 3
