Conveyor / transfer belt for auto tire industry

Our company designs and produces cut-resistant conveyor belt according to characters of parts and components conveying on the high-speed press line of auto industry.

Such type of conveyor belt uses specially treated polyester fiber woven fabric as bearing skeleton, one side or both sides coated with PVC or PU as conveying side or composed with carpet fabric.

Such type of conveyor(transfer) belt features high strength, low elongation, good elasticity, wide working temperature, stable running, long durability.etc. The extraordinary property is it’s high tensile strength with cut resistance, impact resistance, which become the idea complement products of auto part press lines.

Model: SM25

Thickness:4.0mm

Tensile force for 1% elongation:10N/mm

Minimum pulley diameter:100mm

Maximum production width: 2000mm

Model: SU22-26P

Thickness:4.0mm

Tensile force for 1% elongation:12N/mm

Minimum pulley diameter:100mm

Maximum production width: 2000mm

Model: SP32-07

Thickness:2.8mm

Tensile force for 1% elongation:13N/mm

Minimum pulley diameter:100mm

Maximum production width: 3000mm

Model: SP42-14

Thickness:4.0mm

Tensile force for 1% elongation:16N/mm

Minimum pulley diameter:150mm

Maximum production width: 3000mm

Model: SP32-14

Thickness:2.8mm

Tensile force for 1% elongation:13N/mm

Minimum pulley diameter:100mm

Maximum production width: 3000mm

Model: SP22-07B

Thickness:1.3mm

Tensile force for 1% elongation:8N/mm

Minimum pulley diameter:250mm

Maximum production width: 3000mm

Model: SP22-07

Thickness:2.8mm

Tensile force for 1% elongation:8N/mm

Minimum pulley diameter:100mm

Maximum production width: 3000mm
